COMPONENTS AND MATERIALS
- Concealed wall plate – AISI 304 stainless steel. Secured to wall with two screws.
- Main body or rods basket –AISI 304 stainless steel, 2,5mm thickness.
Matt black powder coat (RAL 9004), 115 µm thickness. Secured to wall plate with one Allen stainless steel screw.
- Fixings set - Two Ø 6mm wall plugs, two Ø 4mm screws and one Allen key.
OPERATION
Suitable for hotel...
COMPONENTS AND MATERIALS
- Concealed wall plates (2 units) – AISI 304 stainless steel. Secured to wall with two screws.
- Main body –AISI 304 stainless steel, 2,5mm thickness. Matt black powder coat (RAL 9004), 115 µm thickness. Secured to wall plates with two stainless steel screws.
- Translucent round glass made of glass
- Fixings set - Two Ø 6mm wall plugs, two Ø 4mm screws and one Allen...
1) Brass body and spout in accordance with UNE-EN 1982.
2) Handle made in Zamak.
3) Chrome-plated according to EN 248.
4) Plastic aerator M24x1 with anti-limescale system. Brass housing, chrome.
5) Ceramic cartridge ceramic25
6) Equipped with flexible 35 cm long stainless steel pipes, connectors (M10X100; G 3/8”) and stainless steel mounting kit.
7) Minimum flow: 12 l / min (3 bar).
8)...
1) Body made in brass according to UNE-EN 1982.
2) Lever made in Zamak.
3) Black mate finish.
4) 2 positions free flow D40 ceramic cartridge.
5) Anti-lime M24x1 plastic aerator with black mate brass cover.
6) Fitted with 40 cm long flexible connectors 10x1 F 3/8" and stainless steel horseshoe fixing set.
7) Maximum temperature: 85 °C.
8) Max. recommended temp.: 65 °C.
9) Maximum pressure: 10...
1) Bottle made in brass according to UNE-EN 12165.
2) Arm made in brass according to UNE-EN 12165.
3) Cover made in brass according to UNE-EN 12165.
4) Telescopic tube made in brass according to UNE-EN 12165.
5) Nuts made in brass according to UNE-EN 12165.
6) Chroming plate according to EN 248.
1) Body and plate made in brass according to UNE-EN 1982.
2) Chrome plated according to EN 248.
3) Guided outlet noiseless Ø 40 ceramic cartridge.
4) Anti-lime female M22x1 plastic aerator with chrome plated brass cover.
5) G ½” connectors.
6) Maximum use temperature: 85 °C.
7) Max. recommended temp.: 65 °C.
8) Maximum use pressure: 10 bar.
9) Minimum use pressure: 0,5 bar.
10) Recommended...
1) Body made in brass according to UNE-EN 1982.
2) High-quality bronze finished.
3) Removable cap.
4) Maximum temperature: 85 °C.
5) Max. recommended temp.: 65 °C.
6) Maximum pressure: 10 bar.
7) Minimum pressure: 0,5 bar.
8) Recommended pressure: 1 - 3 bar.
