Timed basin tap to be installed on countertop. Fitted an auto-closing CW617N brass cartridge timed from 7 to 10 seconds (at a 3 bar dynamic pressure) with POM cap, cover and push-button in chrome plated CW617N brass. Body in CC754S brass chrome plated according to EN 248. Fitted with plastic anti-lime economizer aerator with 6 l/min restrainer and plastic anti-particle filter. Includes all the fixation elements.
1) Body made in brass according to UNE-EN 1982.
2) Handle made in zamak.
3) Black matte finish.
4) Conventional D35 ceramic cartridge.
5) Anti-lime M24x1 plastic aerator with chrome plated brass cover.
6) Supplied with PVC shower hose 1,70 m, 3 function shower handle, support, and brass eccentrics for fixing.
7) Maximum temperature: 80 °C.
8) Max. recommended temp.: 65 °C.
9) Maximum pressure:...
1) Body made in brass according to UNE-EN 1982.
2) High-quality black mate finished.
3) Standar connection G ¼”.
4) Telescopic vertical and horizontal connecting pipes.
5) Fitted with NBR gaskets.
6) Maximum temperature: 85 °C.
7) Max. recommended temp.: 65 °C.
8) Recommended pressure: 0.5 bar.
1) Body and plate made in brass according to UNE-EN 1982.
2) Lever made in Zamak.
3) Black mate finish.
4) Conventional D35 ceramic cartridge.
5) Maximum temperature: 85 °C.
6) Max. recommended temp.: 65 °C.
7) Maximum pressure: 10 bar.
8) Minimum pressure: 0,5 bar.
9) Recommended pressure: 1 - 3 bar
1) Made in brass according to UNE-EN1982.
2) Handles in ABS.
3) Chrome plated according to EN 248.
4) Plastic thermostatic cartridge.
5) ¼ turn ceramic headwork
6) Ceramic diverter.
7) Sliding and adjustable rotary holder.
8) Fitted with 1.5 m. chrome plated stainless steel flexible hose, adjustable sprayer with anti-lime jets and 3 anti-lime functions hand shower.
9) Maximum temperature: 85...
1) Body made in brass according to UNE-EN 1982.
2) Chrome plated according to EN 248.
3) Guided outlet noiseless D40 ceramic cartridge.
4) Anti-lime M24x1 plastic aerator with chrome plated brass cover.
5) Fitted with fixing brass eccentrics nuts.
6) Maximum temperature: 85 °C.
7) Max. recommended temp.: 65 °C.
8) Maximum pressure: 10 bar.
9) Minimum pressure: 0,5 bar.
10) Recommended...
Photocell mixer in polished and chromed cast brass
– built-in solenoid valve and battery mounted under the sink
– stop flooding function after 60 seconds of continuous delivery
– anti-legionella function, dispensing for 45 seconds after 24 hours of non-use
– power supply with normal 9V alkaline battery for about 100,000 uses (2 years)
– supplied with 2 stainless steel hoses 350 mm. with special...
1) Made in brass according to EN 12165
2) Chrome plated according to EN 248.
3) Universal valve with / out overflow.
4) Standard connection G 1 ¼”.
5) Removable cap.
COMPONENTS AND MATERIALS
- Concealed wall plate – AISI 304 stainless steel. Secured to wall with two screws.
- Main body –AISI 304 stainless steel, 2,5mm thickness. Matt black powder coat (RAL 9004), 115 µm thickness. Secured to wall plate with one Allen stainless steel screw. This piece consists of the main bar holding the paper roll and the round snap flange hiding and fixing the rear plate....
1) Body made in brass according to UNE-EN 1982.
2) Lever made in Zamak.
3) Chrome plated according to EN 248.
4) Guided outlet noiseless Ø40 ceramic cartridge.
5) M24x1 aerator with chrome plated brass cover.
6) Fitted with chain holder, 60 cm long flexible connectors 10x1 F 3/8" and stainless steel horseshoe fixing set.
7) Maximum temperature: 85 °C.
8) Max. recommended temp.: 65 °C.
9)...
1) Brass body, handle and base, UNE-EN 1982 standard.
2) Chrome-plated according to the EN 248 standard.
3) Built-in noiseless ceramic cartridge Ø40.
4) Aerator M24x1, chromed.
5) Equipped with chain holder, 40cm long M10x1 F ⅜” flexible connectors and stainless steel horseshoe mounting kit
6) Maximum temperature of use: 85 °C.
7) Maximum recommended temperature: 65 °C.
8) Maximum...
Timed basin tap to be installed on countertop. Fitted an auto-closing CW617N brass cartridge timed from 7 to 10 seconds (at a 3 bar dynamic pressure) with POM cap, cover and push-button in chrome plated CW617N brass. Body in CC754S brass chrome plated according to EN 248. Fitted with plastic anti-lime economizer aerator with 6 l/min restrainer and plastic anti-particle filter. Includes all the fixation elements.
