Photocell mixer in polished and chromed cast brass
– with measurements also suitable for installation on a marble top with a built-in sink and on a large-sized sink
– built-in solenoid valve and battery that are easy to replace
– stop flooding function after 60 seconds of continuous delivery
– anti-legionella function, dispensing for 45 seconds after 24 hours of non-use
– power supply with...
1) Body and plate made in brass according to UNE-EN 1982.
2) Lever made in Zamak.
3) Black mate finish
4) Conventional D40 ceramic cartridge.
5) Two positions ceramic diverter.
6) G ½” connectors.
7) Maximum temperature: 85 °C.
8) Max. recommended temp.: 65 °C.
9) Maximum pressure: 10 bar.
10) Minimum pressure: 0,5 bar.
11) Recommended pressure: 1 - 3 bar.
1) Brass body according to UNE-EN 1982.
2) Handles made of Zamak
3) Bronze finish.
4) 1/4" opening, turning ceramic heads.
5) Female M22x1 anti lime aerator. Bronze finish.
6) 35 cm adjustable flexible hose (M10x1; G 3/8”).
7) Minimum flow: 12 l / min (3 bar).
8) Maximum temperature of use: 85 ºC.
9) maximum recommended temperature: 65 º C.
10) Maximum usable pressure: 10 bar.
11)...
1) Body and plate made in brass according to UNE-EN 1982.
2) Lever made in Zamak.
3) Chrome plated according to EN 248.
4) Guided outlet noiseless D25 ceramic cartridge.
5) Anti-lime M24x1 plastic aerator with chromed brass cover.
6) Fitted with plastic filter.
7) Maximum temperature: 85 °C.
8) Max. recommended temp.: 65 °C.
9) Maximum pressure: 10 bar.
10) Minimum pressure: 0,5 bar.
11)...
1) Body and spout made in brass according to UNE-EN 1982.
2) Handle made in Zamak.
3) Chrome plated according to EN 248.
4) Guided outlet noiseless Ø25 ceramic cartridge.
5) Anti-lime F18x1 plastic aerator with chrome plated brass cover.
6) Fitted with 40 cm long flexible connectors M10x1 F ⅜” and stainless steel horseshoe fixing set.
7) Maximum temperature: 85 °C.
8) Max. recommended temp.: 65...
1) Body made in brass according to UNE-EN 1982.
2) Cartridge made in brass according to UNE-EN 12165 with POM cap.
3) Chrome plated according to EN 248
4) Timed cartridge regulated to 7-10 s (at 3 bar).
5) Anti-lime M24x1 plastic aerator.
6) Fitted with brass made fixing nut and plastic filter.
7) Máximun temperature: 85 °C.
8) Max. recommended temp.: 65 °C.
9) Maximum pressure: 10 bar.
10)...
Features:
1) Body, spout and lids made of brass in accordance with UNE-EN 1982.
2) Handle made of Zamak.
3) Chrome-plated according to EN 248.
4) Noiseless ceramic cartridge Ø40.
5) M24x1 plastic aerator with anti-limescale system. Brass body, chrome plated.
6) Maximum temperature of use: 85 ° C.
7) Maximum recommended temperature: 65°C.
8) Maximum usable pressure: 10 bar.
9) Minimum...
COMPONENTS AND MATERIALS
- Concealed wall plate – AISI 304 stainless steel. Secured to wall with two screws.
- Main body –AISI 304 stainless steel, 2,5mm thickness. Matt black powder coat (RAL 9004), 115 µm thickness. Secured to wall plate with one Allen stainless steel screw. This piece consists of the main bar holding the paper roll and the round snap flange hiding and fixing the rear plate....
1) Body made in brass according to UNE-EN 1982.
2) Handle made in zamak.
3) Chrome plated according to EN 248.
4) D25 ceramic cartridge with top seal.
5) 5-liter anti-vandal economizer aerator.
6) Supplied with 8x1 connection set - H 3/8" at 50 cm DN6 and nut fixing system by means of a nut on a threaded tube.
7) Maximum temperature: 80 °C.
8) Max. recommended temp.: 65 °C.
9) Maximum pressure:...
1) Body made in brass according to UNEEN 1982.
2) Handle made in zamak.
3) Chrome plated according to EN 248.
4) D35 ceramic cartridge with guided outlet.
5) G 1/2" connectors.
6) Maximum temperature: 80 °C.
7) Max. recommended temp.: 65 °C.
8) Maximum pressure: 10 bar.
9) Minimum pressure: 0,5 bar.
10) Recommended pressure: 1 - 3 bar.
