The submersible pump is designed for pumping dirty, technological and sewage water, contaminated with solid elements of organic origin and textile particles, also with intimate hygiene products. It can pump septic tank, gray water, cold water, fresh water without grinding elements.
Deep well pumps are designed to draw clean, cold water from drilled deep water intakes, vertebral wells and other water reservoirs. Designed for installation in wells with a minimum diameter of 110mm. The pump should not pump water with solid grinding parts, however, the design of the pumps allows for pumping water with sand content up to 5% max.
Technical data:
Maximum water temperature 35 °...
Submersible pumps are aggregates made entirely of stainless steel, installed in wells with a minimum diameter of 110mm. They are designed for pumping clean, cold water that does not contain solid grinding or long-fiber elements.
Technical data:
Maximum water temperature 35 ° C
Protection degree IP 68
Winding insulation class B
Number of starts up to [x / hour] 20
Minimum cooling flow of the...
OPERATING CONDITIONS
- Liquid temperature up to 35°C
(for home use according to EN 60335-2-41)
Max. liquid temperature: 35°C (for other uses)
- Ambient temperature up to 40°C
MOTOR
- r.p.m. 3600
- Start system recoil
- Tank capacity 3,6 lt
MATERIALS
- Pump body Aluminium
- Motor Support Aluminium
- Impeller Cast Iron
- Mechanical seal Ceramic
- Graphite/NBR
The submersible pump with a grinder is dedicated to pumping sewage, slurry and dirty water with the presence of organic and household contaminants. The pump has an efficient grinding system which initially cuts the pumped medium into pieces, thanks to which there is no clogging of the discharge section in the pipeline. The pump has a float control which controls switching on depending on the...
Maximum capacity: 195 l/min
Maximum lifting height: 7 m
Motor power: 0.55 kW
Voltage: 230V
discharge port: 1"
Power cable length: 10 m
Size of impurities max.: 25 mm
Maximum water temperature 35°C
Degree of protection IP 68
Maximum immersion depth [meters] 10
Vertical work position
material version:
Technopolymer housing
PPO technopolymer impeller
Plastic inlet screen
Plastic pump cover
Maximum capacity: 583 l/min
Maximum lifting height: 23 m
Motor power: 2.2 kW
Voltage: 230V
discharge port: 2"
Power cable length: 8 m
Technical data:
Maximum water temperature 35°C
Degree of protection IP 68
Maximum immersion depth [meters] 10
Vertical work position
material version:
Stainless steel pump housing
Cast iron impeller
Stainless steel shredding system
Pump shaft stainless steel
Maximum capacity: 330 l/min
Maximum lifting height: 9 m
Motor power: 1.1 kW
Voltage: 230V
Discharge port: 2"/65mm
Power cable length: 9.5 m
Size of impurities max.: 25 mm
Technical data:
Maximum water temperature 35°C
Degree of protection IP 68
Maximum immersion depth [meters] 10
Working position vertical
material version:
Motor housing stainless steel
Cast iron impeller
Cast iron rotor...
Multistage submersible pump designed for pumping fresh, clean, cold water from vertebral wells and large-size tanks. The design of the pump allows it to be connected directly to the water system, bypassing the diaphragm tank and pressure switch, which significantly reduces installation costs. The operation of the MULTI DIVER 1200 EVO is controlled automatically by means of a built-in electronic...
Technical data:
Size of filtered impurities > 120
Maximum working pressure 10 Bar
Connection size 1"
Maximum flow 120 l/min
Material version:
Plastic housing
Stainless steel mesh
Plastic discs
Deep well pumps are designed to draw clean, cold water from drilled deep water intakes, vertebral wells and other water reservoirs. Designed for installation in wells with a minimum diameter of 110mm. The pump should not pump water with solid grinding parts, however, the design of the pumps allows for pumping water with sand content up to 5% max.
Technical data:
Maximum water temperature 35 °...
A. Uniformed services: fire, police, army
B. Industry and service sectors
C. Outdoor recreational facilities and winter sports resorts
A modern device designed specifically for the outlined function, incorporating a zinc-coated steel structure, electrostatically painted – color RAL 7035, structure. Leveling feet, retractable power cord, L = 2.3 m long. Patent lock. The cabinet has an intuitive...
The multi-stage pump is designed for pumping clean, cold, fresh water from ring wells and other reservoirs. The pump is the right choice for domestic irrigation and drainage applications.
Maximum water temperature 35°C
Degree of protection IP X8
material version:
Pump housing stainless steel / technopolymer
Mechanical gland silicon carbide - graphite
Technopolymer impeller
Suction screens /...
Maximum capacity: 330 l/min
Maximum lifting height: 9 m
Motor power: 1.1 kW
Voltage: 230V
discharge port: 2"
Power cable length: 6 m
Size of impurities max.: 15 mm
Technical data:
Maximum water temperature 35°C
Degree of protection IP 68
Insulation class B
Working position vertical
material version:
Cast iron pump housing
Cast iron impeller
Stainless steel inlet screen
Cast iron pump lid
• Working with medium under pressure
• Robust workmanship
• Resistant to abrasion and UV radiation
• Light weight
• Flat - at rest
• Large selection of sizes
Temperature of the medium 0°C ÷ 60°C
Bursting pressure 6 bar
Working pressure 4 bar
External enclosure PE
Inner casing PE
Reinforcement polyester
A discharge hose that can be rolled up significantly reduces the hydraulic performance of the...
The submersible pump is designed for pumping dirty, technological and sewage water, contaminated with solid elements of organic origin and textile particles, also with intimate hygiene products. It can pump septic tank, gray water, cold water, fresh water without grinding elements.
