Check valve with filter
€4.04
PN 10. Body brass UNE-EN 12165. Gas threaded ends ISO 228/1 - F. Max. temp. 90ºC. Vulvanized NBR sealing. Stainless steel spring and sleve AISI 304. Minimum working pressure 20 - 60 mbar.
Trusted client
Trusted delivery
1. Check valve.
2. Brass construction acc/ UNE-EN 12165.
3. Thread ends gas (BSP) female acc/ ISO 228/1.
4. Working temperature from -20ºC to 100ºC.
5. Suitable for domestic water services, heating and air-conditioning plants and compressed air systems.
6. It can be fitted in horizontal, vertical or oblique position.
7. With inlet strainer.
8. NBR sealing (rubber) 65 shore.
9. Stainless Steel spring AISI 302.
10. Maximum working pressure 12/10/6 bar (PN-12/
PN-10/ PN-6)
PL314200
