ClassicLine body safety shower, floor mounted

€1,004.06
Tax included
In stock at the supplier Quantity
0 review(s)
  • The freestanding industrial safety showers are always used when wall mounting of the shower is not possible or when a central point of contact for first aid is to be created. It also makes sense to use them in large halls and production facilities. A big advantage is the good visibility of the shower from all sides. The freestanding safety showers can be optionally adapted to the requirements on site with a wide range of options.

    Technical Specifications

    Minimum flow pressure: 1.5 bar

    Operating pressure: 1.5 to 3 bar

    Flow rate: 50 l/min

    Water inlet: 1 ¼” female

    ClassicLine body safety shower, floor mounted

    - including top and bottom water inlet 1 ¼” female for installation in circulation lines, plug 1 ¼” of stainless steel

    - base plate with 4 mounting holes of stainless steel, chemical resistant green powder coated, diameter 200 mm

    - stand pipe 1 ¼” of stainless steel three-part, chemical resistant green powder coated, with top and bottom water inlet 1 ¼” female, total height 2330 mm

    - connection piece of stainless steel, for easy installation and alignment of the shower

    - ball valve ¾” of brass, with quick connect system and pull rod actuation, DIN-DVGW tested and certificated

    - pull rod with ring handle of stainless steel, chemical resistant green powder coated, length 700 mm

    - wall shower arm ¾“ of stainless steel, chemical resistant green powder coated, projection 630 mm

    - integrated automatic flow regulation 50 l/min. for a spray pattern acc. to the norms at a specified operating range of 1.5 to 3 bar dynamic water pressure

    - high-performance shower head of chemical resistant plastics, black, with improved spray pattern, corrosion resistant, largely free of calcification-and maintenance, very robust, self-draining

    - sign for body safety shower according to EN ISO 7010 und ASR A1.3, self-adhesive PVC-film, 150 x 150 mm, viewing distance 15 metre

    - according to BGI/GUV-I 850-0, DIN 1988 and EN 1717

    - according to ANSI Z358.1-2014, EN 15154-1:2006 and EN 15154-5:2019
    - DIN-DVGW tested and certificated

    PL830 085
